45 degree movable cabinet & white color
-
Single armrest & multifunctional pedal switch
-
Removable & rotable spittoon
-
Assistant control system & LED sensor cold oral light
-
12mm thicknes chair frame
-
USB type central control system
Technical Spesification :
Category |
AY-A2000 |
Input Voltage |
AC110V/220V 60Hz/50Hz |
Water Pressure |
2.0-4.0bar |
Air Pressure |
5-8.0bar |
Output (water vacuum) |
≥55L/min |
Output (air vacuum) |
≥55L/min |
Weight |
235kg |
Chair Patient: Max Load |
180kg |
Chair Patient: Handrest |
1 |
Chair Patient: Headrest |
Flat |
High speed handpiece |
2 pcs |
Low speed handpiece |
1 pc |
3-Way Syringe |
2 pcs |
Strong suction |
1 pc |
saliva ejector(weak suction) |
1 pc |
LED Curing Light |
1 pc |
LED Scaler Woodpecker |
1 pc |
Doctor Instrument Tray: Rotation |
135º |
Doctor Instrument Tray: Instrument Racks |
5 |
Doctor Instrument Tray: Control Panel Buttons |
11 |
Doctor Instrument Tray: Film Viewer |
Yes |
Doctor Instrument Tray: Max Load |
≤6kg |
Doctor Instrument Tray: Detachable Silicon Pad |
Yes |
Operation Light: Type |
Reflective Sensor Light |
Operation Light: Intensity |
7000lux – 30000lux |
Foot Controller: Max Load |
150kg |
Foot Controller: Functions |
Movement/chip blow/water/air control |
Assistant Tray: Instrument Racks |
4 |
Assistant Tray: Control Panel Buttons |
7 |
Assistant Tray: Rotation |
90º |
Cuspidor: Rotation |
180º |
Cuspidor: Material |
Detachable Ceramic |
Doctor Stool: Material |
PU (Polyurethane) Tahan Haus |
Air Compressor: Power |
550 W |
Air Compressor: Volume Flow |
70L/min |
Air Compressor: Actuating Pressure |
0.5Mpa |
Air Compressor: Rated Exhaust Pressurer |
0.77Mpa |
Air Compressor: Gas Holder Volume |
32L |
Air Compressor: Noise |
55-62 dB |
